Ergotron MX Desk Mount Monitor Arm

The sleek MX LCD Arm accommodates mid-size displays and all-in-one computers weighing up to 30 lbs (13.6 kg). Five inches (13 cm) of height adjustment, extension/retraction motion, integrated tilt and portrait-to-landscape capability promote user comfort and enhance productivity.

Benefits:

• Accommodates mid-size displays and all-in-one computers weighing up to 30 lbs (13.6 kg)
• Position your display for maximum ergonomic comfort to relieve eye, neck and back strain
• Free up your table or desktop to increase your workspace
• Upgrade LCD monitors and TVs with improved ergonomic adjustment
• Pre-assembled arm offers monitor/TV theft deterrence
• Rotate screen for portrait viewing of photos and pages—eliminate scrolling
• Cable management feature conceals and routes cables under the arm, out of the way
• Extends/retracts LCD up to 16.7" (424 mm); push your display out of the way when not in use
• Easy-to-use, simple installation and effortless operation
  Features:
• MX Desk Mount LCD Arm (polished aluminum)
• Includes desk clamp and grommet mount
• Mounting Options: Desk clamp attaches to surface edge 2.6" (66 mm) thick; grommet mount attaches through surface holes .31" to 2.0" (8 to 51 mm) wide and up to 3" (80 mm) thick
• Weight Capacity: 14 to 30 lbs (6.3 to 13.6 kg)
• Monitor depth greater than 4" (102 mm) may diminish capacity. Contact Ergotron for more information
• Pans at base 180°; rotates at extension 360°; pans at monitor 180°
• Monitor tilts 75° up and 5° down
• Extends/retracts LCD up to 16.7" (424 mm)
• Motion range may be limited when using larger displays and/or by the position of the VESA hole pattern on the back of the display
• Portrait/landscape rotation includes position lock
• Portrait mode is incompatible with 30" displays
• Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole pattern = 100 x 100 mm & 75 x 75 mm); VESA FDMI, MIS-E, C (hole pattern = 200 x 100 mm); VESA FDMI, MIS-F, C (hole pattern = 200 x 200 mm)
• Polished aluminum finish
• Internal cable managementSpecifications:

• Part # 45-214-026
• LCD Size max is 30"
• Maximum weight allowance 14-30lbs (6.3.- 13.6kg)
• Lift 5" (30cm)
• Tilt 80 degrees
• Pan 360 degrees
• Rotation 90 degrees
• Shipping Dimensions: 25.6" x 7.3" x 6.3" (65 x 18.5 x 16 cm)
• Shipping Weight: 9 lbs (4.2 kg)
• Warranty: Five (5) years
