Ergotron Workfit TL Monitor Kits

Upgrade your WorkFit to hold your screens above the desktop. Offers 5" (13 cm) of height adjustment and tilt. Easily lift and tilt the screen to proper height for unsurpassed ergonomic comfort.

Simple installation and effortless operation Accommodates an upgrade to your computer system, allowing you to reuse your WorkFit in a different hardware configuration

Single Screen LD

• Part Number: 97-905
• Description: WorkFit-T Single LD Monitor Kit (black)
• Includes 5" lift engine, one (1) LD monitor pivot, cable management tube and ties, attachment hardware.
• Compatible with WorkFit-T and WorkFit-PD products
• Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
• Maximum outside width of display is 24.5" (62 cm) when displays are 2" (5 cm) thick. Accommodates most displays with screen-size up to 24" as well as some displays with screens as large as 26". Actual allowable width of displays will vary slightly depending on display thickness
• Weight Capacity: LCD mount capacity = 6–16 lbs (2.7–7.3 kg)
• When added to WorkFit-T, overall capacity of the WorkFit-T decreases from 35 lbs (15.9 kg) to 28.4 lbs (12.9 kg)
• Shipping Dimensions: 25.2" x 5" x 6.9" (64 x 13 x 17 cm)
• Shipping Weight: 11.4 lbs (5.2 kg)
• Warranty: Five (5) years

Single Screen HD

• Part Number: 97-906
• Description: WorkFit-T Single HD Monitor Kit (black)
• Includes 5" lift engine, one (1) HD monitor pivot, cable management tube and ties, attachment hardware.
• Compatible with WorkFit-T and WorkFit-PD products
• Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
• Accommodates most displays with screen-size up to 30". Actual allowable width of displays will vary slightly depending on display thickness
• Weight Capacity: LCD mount capacity = 16 - 28lbs (7.3 - 12.7 kg)
• When added to WorkFit-T, overall capacity of the WorkFit-T decreases from 35 lbs (15.9 kg) to 28.4 lbs (12.9 kg)
• Shipping Dimensions: 25.2" x 5" x 6.9" (64 x 13 x 17 cm)
• Shipping Weight: 11.4 lbs (4.1 kg)
• Warranty: Five (5) years

Dual Screen

• Part Number: 97-934-085 (old code was 97-904)
• Description: WorkFit-T Dual Monitor Kit (black)
• Includes 5" lift engine, two (2) monitor pivots, dual bow, cable management tube & ties, attachement hardware compatible with the Workfit-T & Workfit-PD products
• Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
• Maximum outside width of display is 24.5" (62 cm) when displays are 2" (5 cm) thick. Accommodates most displays with screen-size up to 24" as well as some displays with screens as large as 26". Actual allowable width of displays will vary slightly depending on display thickness
• Weight Capacity: LCD mount capacity = 6–14 lbs (2.7–6.3 kg) each, 12–28 lbs (5.5—12.7 kg) total
• When added to WorkFit-T, overall capacity of the WorkFit-T decreases from 35 lbs (15.9 kg) to 25.3 lbs (11.5 kg)
• Shipping Dimensions: 30.5" x 9.6" x 5.2" (77.5 x 24 x 13 cm)
• Shipping Weight: 11.4 lbs (5.2 kg)
• Warranty: Five (5) years

Single LCD & Laptop

• Part Number: 97-907
• Description: WorkFit-T Single LCD & Laptop Kit (black)
• Includes 5" lift engine, one (1) monitor pivot, one (1) laptop tray, dual bow, cable management tube and ties, attachment hardware
• Compatible with WorkFit-T and WorkFit-PD products
• Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
• Accommodates most displays with screen-size up to 24". Actual allowable width of displays will vary slightly depending on display thickness
• LCD mount capacity = 6–16 lbs (2.7–7.3 kg), laptop tray ≤ 10 lbs (4.5 kg), 12–26 lbs (5.5—11.8 kg) total
• When added to WorkFit-T, overall capacity of the WorkFit-T decreases from 35 lbs (15.9 kg) to 24.9 lbs (11.3 kg)
• Shipping Dimensions: 30.5" x 17.3" x 5.7" (77.5 x 44 x 15 cm)
• Shipping Weight: 15.4 lbs (7 kg)
• Warranty: Five (5) years

Dual Tall User Kit

Converts a WorkFit TL Dual so that it reaches the ergonomic height requirements of taller users who are 6'3" (190 cm) or over.

• Part Number: 97-615
• Accommodate the height needs of tall users and improve the ergonomics of your workstation for prolonged sitting or standing applications
• Easy-to-use-simple installation and effortless operation
• Adds 30° of up/down tilt to display
• Includes: 2 x Single Monitor Pivots, 2 x Riser Brackets, Installation Hardware
• Warranty: Five (5) years
